LTS-23
Wireless control system with weekly regulator
The LTS-21 set enables wireless control of any heating device or pump. It consists of the LBW-23 weekly battery- -powered regulator and the LOT-21 regulator receiver. The regulator controls the temperature in the room based on a weekly schedule. Information about the need to turn on/off the heating device or pump is sent via radio to the LOT-21 receiver, which physically performs the control function. The set, in cooperation with the EFC-01 controller, can be operated via the Exta Life mobile application.
– set paired and ready to work,
– modes: floor protection, holiday, party, anti-freeze protection,
– wireless communication,
– control based on four temperatures and a weekly schedule,
– floor protection mode,
– implementation of special modes: holiday, party, antifreeze protection,
– signal renewal mechanism,
– temperature setting range from + 5°C to + 95°C,
– control based on hysteresis or TPI,
– ability to place the regulator anywhere,
– compatibility with the mobile application Exta Life (via EFC-01),
– white / black colour version.
Regulator power supply: 2 x LR03 AAA batteries
Receiver power supply: 230 V AC 50 / 60 Hz
Transmission: radio 868,50 MHz
Range: up to 300 m
Receiver output: NO voltage-free NO contact
Maximum receiver load: 8A / 230 VAC
Control algorithm: hysteresis or TPI
Installation: Receiver (surface-mounted), Regulator (surface-mounted or standalone)
