SOP-01
Thermoelectric actuator powered by 230 V M30 X 1,5
SOP-01 is a thermoelectric actuator designed to control the flow of the heating factor in installations. The use of the actuator ensures thermal comfort and significantly reduces heating costs. It is equipped with an M30 x 1.5 thread.
– for use with valve inserts in manifolds,
– NC version (normally closed),
– maximum stroke 4 mm,
– housing protection level IP54,
– factory cable 70 cm long,
– actuator secured with a cotter pin enabling installation checking without the need to remove the actuator, durable and weather-resistant housing.
Power supply: 230 V ~
Thread: M30 x 1,5
Power consumption: ~2 W
Pressing force: 100 N
Maximum stroke: 4 mm
Type: NC
Cable: 2 x 0,75 mm² 0,7 m
