ROG-21
Radio socket
The ROG-21 radio socket is the final element of the EXTA LIFE system, which allows you to control any receivers in your home or office. It works with devices with a voltage of 230 V AC and a maximum load of 13 A. The current status of the controlled device and the amount of electricity consumed by it are displayed in the mobile application.
– easy installation directly in a 230 V socket,
– compatible with the EFC-01 controller and Exta Life system transmitters,
– ability to configure selected parameters, 4 operating modes in cooperation with transmitters (switch on/off, bistable, monostable, timer),
– 2 operating modes in cooperation with the controller (switch on/off, timer),
– measurement of basic network parameters (voltage, current),
– measurement of active power and energy consumption,
– estimating the energy consumption costs of a device connected to the socket,
– visualizing energy consumption in the form of graphs in the application (day, week, month, year) and exporting energy consumption data.
Power supply: 230 V AC
Frequency:: 50 / 60 Hz
Power consumption: 0,60 W (standby)
Transmission: Radio 868,50 MHz
Range: up to 250 m
Maximum load: 13 A for resistive loads, 8 A for loads with cos Ø = 0.5
Installation: Directly in a 230 V socket
