RTM-20
Temperature regulator + 5 ÷ + 60 °C without sensor 230 V
The RTM-20 digital temperature regulator is used to control receivers (e.g. radiators, underfloor heating) depending on the temperature surrounding the external NTC sensor. The device has the ability to adjust the set temperature in the range from + 5 °C to + 60 °C and a digital LCD display.
– Temperature regulation in the range of 5 °C ÷ 60 °C,
– external sensor – NTC-03 sensor,
– LCD display and keyboard,
– control of receivers depending on temperature,
– 2-module housing with a flap, installation on a DIN rail,
– relay output with a maximum load of 16 A.
Power supply terminals: A1, A2
Power supply: 230 V~
Frequency: 50 / 60 Hz
NTC sensor terminal: NTC
Supported sensor: NTC 10 k
Temperature setting range: + 5 ÷ + 60 °C
Working position: any
Installation: DIN rail
